M24128-BRMN6TP 128-Kbit serial I²C bus EEPROM 1.8V~5.5V 1MHz I2C

Brand Name : ST

Model Number : M24128-BRMN6TP

Certification : rohs

Place of Origin : CN

MOQ : 1

Price : consult with

Payment Terms : T/T,Western Union

Supply Ability : 100000

Delivery Time : 5-8days

Packaging Details : T/R

Operating Temperature : -40℃~+85℃

operating voltage : 1.8V~5.5V

Interface Type : I2C

Storage Capadity : 128Kbit

Clock Frequency (fc) : 1MHz

Write Cycle Time (Tw) : 5ms

Contact Now

M24128-BRMN6TP 128-Kbit Serial I²C Bus EEPROM

1.8V~5.5V 1MHz I2C

FM24128-BRMN6TP 128-Kbit serial I²C bus EEPROM 1.8V~5.5V 1MHz I2C

M24128-BW M24128-BRM24128-BF M24128-DF

Key Features

Compatible with all I2C bus modes: 1 MHz, 400 kHz, 100 kHz
Memory array: 128 Kbit (16 Kbyte) of EEPROM
Page size: 64 byte
Additional Write lockable page (M24128-D order codes)
Single supply voltage and high speed: 1 MHz clock from 1.7 V to 5.5 V
Write operations: Byte Write within 5 ms, Page Write within 5 ms
Operating temperature range: -40 °C to +85 °C
Random and sequential Read modes
Write protect of the whole memory array
Enhanced ESD/Latch-Up protection
More than 4 million Write cycles
More than 200-years data retention

Signal Names & Functions

Signal Name	Function	Direction
E2, E1, E0	Chip Enable	Input
SDA	Serial Data	I/O
SCL	Serial Clock	Input
WC	Write Control	Input
VCC	Supply voltage	-
VSS	Ground	-

Product Documentation

M24128-BRMN6TP 128-Kbit serial I²C bus EEPROM 1.8V~5.5V 1MHz I2C

Packaging & Shipping

Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.

Frequently Asked Questions

How to obtain the price?

We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.

What is your delivery time?

Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.

What are your payment terms?

Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.

What are the shipping options?

Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
